P4S8X Audio Panel Connector
FP_AUDIO
LineOut_RL
MIC
LineOut_FR
LineOut_FL
NC
MICPWR
NC
AGND
LineOut_RR
24. Front panel audio connector (10-1 pin FP_AUDIO)
(on audio models only)
This is an interface for the Intel
®
front panel audio cable that supplies
convenient connection and control of audio devices.
Ensure that the jumper caps are removed from the FP_LO_SWR and
FP_LO_SWL jumpers if you installed the Intel front panel audio cable.
Refer to page 25 for the location of the audio jumpers.
