Auto Page C3-RS1100 User Manual
Page 2
C3 RS1100REV. A
2
TABLE OF CONTENTS:
INSTALLATION DIAGRAMS
4
H1: 6 PIN HEAVY GAUGE WIRING CONNECTION
6
H1/1 Violet Wire – Starter Output
6
H1/2 & H1/3 Red Wire – +12V Power Input
7
H1/4 Yellow Wire – Ignition 1 Output
7
H1/5 Pink Wire – Ignition 2 Output
7
H1/6 Brown Wire – Accessory Output (Heater /ACC Output)
7
H5: 5 PIN WHITE WIRE HARNESS
8
H5/1 Red / White wire – Parking Light Relay Power Input
8
H5/2 White wire – Parking Light Relay Output
8
H5/3 Black wire – System Ground
8
H5/4 Brown wire – Siren Drive Output
8
H5/5 Red wire – System Power
8
H7: 4-PIN BLACK CONNECTOR TWO-WAY TRANSCEIVER/ANTENNA MODULE
9
H8. 2 PIN BLUE CONNECTOR FOR THE VALET SWITCH
9
H3. 2 PIN WHITE CONNECTOR FOR THE LED STATUS INDICATOR
9
H9. 4 PIN ORANGE CONNECTOR FOR 2 STAGE SHOCK SENSOR (ZONE 1/4)
10
H6: 22 PIN WIRE CONNECTOR
10
H2 C3 SERIAL DATA PORT CONNECTION RS -232 Port
16
H4. 3 PIN DOOR LOCK CONNECTOR (maximum 500 mA output)
17
Negative Trigger Door Lock System
17
Positive Trigger Door Lock System
17
Alternating Door Lock System
17
Vacuum Operate Door Locking System
17
2 Steps Door Unlock Wire Connection -5 Wires Alternating Lock System
18
2 Steps Door Unlock Wire Connection - (-) Switched Door Lock System
18
2 Steps Door Unlock Wire Connection - (+) Switched Door Lock System
18
PROGRAMMING & TESTING:
PROGRAM MING THE REMOTE TRANSMITTER
19
FEATURES PROGRAMMING
19
Alarm Feature “A” Programming
19
Alarm Feature “B” Programming
20
Alarm Feature “C” Programming
22
Channel 4 Timer Control Output Programming
23
Password Pin Code Setup
24
Start Feature “D” Programming
24
Start Feature “E” Programming
25
Tachometer Checking Type – RPM Learning & Testing
26
Voltage Checking Type – Start Timer Set-up & Testing
27
Timer Checking Type – Start Timer Set-up & Testing
28
Test Mode
28
RETURN TO FACTORY DEFAULT SETTING
29
TROUBLE SHOOTING
30
SHUTDOWN DIAGNOSTICS
30
TESTING YOUR INSTALLATION
30
Test the Brake shutdown circuit
31
Test the Hood Pin shutdown circuit
31
Neutral Start Safety Test
31
