Specifications
500 H3 Reverse
The ABL 500 series halogen is designed for tough work
environments. With a fibre reinforced plastic housing and
hardened glass lens, this Backlight 500 H3 Reverse series
are dedicated for homologated reverse light systems
requested by truck and vehicles road regulations.
Accessories - Service Lights
Dimensions
Dimension unit in mm (10 th inch)
Pedestal Suspended
Mounting
Bulb: H3 bulb, 70W max
Light pattern: Flood ECE R23 - ADR Approved
Voltage: 12V, 24V, 36V, 48V, 80V
Intensity: 2,92 Amp @ 24V (for 24V 70W bulb)
Operating Temp: -40°C to +60°C
Salt Spray: ISO 9227
Housing: black fibre reinforced plastic
Lens: hardened glass
Reflector: aluminum
Premium lighting solutions www.abllights.com
104 (4.094)
94 (3.701)
83 (3.268)
125 (4.921)
Connection
Built-in
AMP
Built-in
DT
Grommet Wires
compression seal
(Glafsa)
PG7/PG9
compression seal
