ABL Lights Group Alpha 225 Pro - Manual (Page 2)

Bulb: H1 bulb
Light pattern:
ECE Position Light LED
ECE Broad 37,5
Off Road Pencil
Consumption: 70W max
Voltage: 12V, 24V
Intensity: 2,92 Amp @ 24V (for 24V 70W bulb)
Operating Temp: -40°C to +60°C
Salt Spray: ISO 9227
Housing: aluminum
Lens: hardened glass
Reflector: aluminum
Specifications
Accessories - Auxiliary Lights
Alpha 225 Pro
Alpha 225 Pro Halogen is an auxiliary light with a robust
aluminum housing and bezel. This light both widen and
extend your normal head light pattern. Alpha 225 Pro is
also more resistant to vibration and ensures added safety
through outstanding performance.
Dimensions
128±2 (5.039±0.078) ø225±2 (8.858±0.078)
237
±2 (9.330
±0.078)
M10
Dimension unit in mm (10 th inch)
Connection
Grommet Wiring harness
Mounting
Pedestal
Options
Blue Lens
Suspended
Black Bezel
Light Patterns
Broad
200 400 m
0
m
20
20
Pencil
200 400 500 m
0
m
20
20
