ABL Lights Group Alpha 225 Xenon - Manual (Page 2)

Bulb: 35W D1S, Gen 5 integrated ballast
Light pattern:
ECE Position Light LED
ECE Broad 20
Off Road Pencil
Consumption: 43W
Voltage: 12V, 24V
Intensity: 1,8 Amp @ 24 Vdc
Operating Temp: -40°C to +60°C
Salt Spray: ISO 9227
Housing: black fibre reinforced plastic
Lens: plastic lens
Reflector: plastic
Specifications
Accessories - Auxiliary Lights
Alpha 225 Xenon
Alpha 225 Xenon is an auxiliary light equipped with an HID
(Xenon) bulb. The HID (Xenon) bulb offers three times the
light with lower power consumption than halogen. Alpha
225 Xenon will both widen and extend your normal vehicle
head lamps through outstanding performance.
Dimensions
250
±2 (9.842
±0.078)
ø225±2 (8.858±0.078)
M10
153±2 (6.023±0.078)
Dimension unit in mm (10 th inch)
Connection
Wiring harness
Mounting
Pedestal
Options
Blue Lens
Light Patterns
Broad
200 400 m
0
m
20
20
Pencil
200 400 600 800 1000 m
0
m
20
20
Premium lighting solutions www.abllights.com
