ABL Lights Group Alpha 225 Pro Xenon - Manual (Page 2)

Bulb: 35W D1S, Gen 5 integrated ballast
Light pattern:
ECE Position Light LED
ECE Broad 45
Off Road Pencil
Consumption: 43W
Voltage: 12V, 24V
Intensity: 1,8 Amp @ 24 Vdc
Operating Temp: -40°C to +60°C
Salt Spray: ISO 9227
Housing: aluminum
Lens: hardened glass
Reflector: aluminum
Specifications
Accessories - Auxiliary Lights
Alpha 225 Pro Xenon
Alpha 225 Pro Xenon is an auxiliary light with a robust
aluminum housing and bezel. The HID (Xenon) bulb offers
three times the light with lower power consumption
than halogen. Alpha 225 Pro is also more resistant to
vibration and ensures added safety through outstanding
performance.
Dimensions
ø225±2 (8.858±0.078)
237
±2 (9.330
±0.078)
151±2 (5.944±0.078)
M10
Dimension unit in mm (10 th inch)
Connection
Grommet Wiring harness
Mounting
Pedestal
Options
Black Bezel Blue Lens
Suspended
Light Patterns
Broad
200 400 500 m
0
m
20
20
Pencil
200 400 800 1000 m 600
0
m
20
20
Premium lighting solutions www.abllights.com
