ABL Lights Group ABL 1100 H3 - Manual (Page 2)

Bulb: H3 bulb, 70W max
Light pattern: Flood
Voltage: 12V, 24V, 36V, 48V, 80V
Intensity: 2,92 Amp @ 24V (for 24V 70W bulb)
Vibration resistance: 10 Grms from 24 to 2000Hz
Water Tightness:
IP 54 for Grommet
IP 65 for specific cable, built-in connectors
and compression seals
Operating Temp: -40°C to +85°C
Salt Spray: ISO 9227
Housing: black fibre reinforced plastic
Lens: hardened glass lens
Specifications
ABL 1100 H3
The ABL 1100 series work lamps provide optimal light
at the most economical value. Sold by the millions, the ABL
1100 family has firmly established itself as a standard work
light for demanding users.
Heavy Duty - Work Lights
Side mount
Dimensions
86 (3.386) 155 (6.102)
95 (3.740)
125 (4.921)
Dimension unit in mm (10 th inch)
Connection
Built-in
AMP
Built-in
DT
Grommet Wires
compression seal
(Glafsa)
Mounting
Suspended
Options Light Patterns
Flood
Pedestal
Antivibration
bracket
Magnetic base Clear Plastic
Premium lighting solutions www.abllights.com
