PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY

5. After making sure the air charge is correct, replace the 1 1/2” plug over the

air valve.

6. The EXTROL

®

may now be piped to the system (use the suggested

EXTROL

®

piping diagrams on the next page).

7. Using the table below, select appropriate pipe size. Connection to each

EXTROL

®

must have a lock shield gate valve and union to allow isolation and

removal if required. Make up and fill valves, whether manual or automatic,
should be tied into the connecting line. This will ensure that pump operation
will not affect valve operation.

Operational Limits

Maximum Operating Pressure: As stamped on nameplate
Maximum Operating Temperature: 240 °F
Minimum Operating Temperature: 35°F (non-glycol application)
If unit is being installed in a glycol system where minimum temperatures
fall below 35°F, contact the AMTROL technical service department at (401)
535-1216.

Operating Instructions

1. Check the expansion tank pre-charge before the system is filled with water.

The charge is 12 psig unless noted otherwise on the tank label. Check to
make sure this is the correct pre-charge pressure specified for the system.

2. If the tank pre-charge pressure needs to be changed on a dry system follow

the following procedure:

a. Check the expansion tank air pressures at the pre-charge connection with

an accurate tire type pressure gauge. The pre-charge connection is the same
kind of connection found on automobile tires.

b. If the pressure is low, charge the tank with nitrogen gas or with oil free

compressed air. Check the pressure frequently during this process as you
would when filling a tire with air.

Danger: Excessive pressure can cause tank to explode. Exercise
care when filling a tank with air so the pressure does not exceed
that required or does not exceed the working pressure of the

tank as stamped on the nameplate. Failure to follow these instructions will
result in serious personal injury or death and property damage.

3. If, after the system has been filled with water and operating, it is found that

the expansion tank pre-charge must be changed use the following procedure:

a. Turn off the heat source and allow the system water to cool to ambient

temperature.

b. Close the lock-shield valve in the tank-to-system piping.

IMPORTANT: Expansion tank cannot be properly air charged
other than at ambient temperature.

c. Open the drain valve to empty the water from the tank.

d. Check the tank air pressure at the pre-charge connection with an accurate

tire type air gauge.

e. Refer to 2b above.
f. Close the drain valve, open the lock-shield valve and turn on the heat

source.

g. Relock the lock-shield valve.

Potable Water and Radiant Heating Warning.

This Product must not be used in radiant

heating, potable water or open systems of any kind. These systems

contain oxygenated water which will cause internal corrosion and

premature Product failure. Use a Therm-X-Trol

®

for potable water

systems and a Radiant Extrol™ for radiant heating systems. Mount

vertically only. Do not install on dead-end pipe.
IMPORTANT GENERAL SAFETY INFORMATION - ADDITIONAL

SPECIFIC SAFETY ALERTS APPEAR IN THE FOLLOWING

INSTRUCTIONS.
Note: Inspect for shipping damage and notify freight carrier or

store where purchased immediately if damage is present. To avoid

risk of personal injury and property damage, if the product appears

to be malfunctioning or shows signs of corrosion, call a qualified

professional immediately. Current copies of the Product manual

can be viewed at www.amtrol.com. Use proper safety equipment

when installing.

FAILURE TO PROPERLY SEAL WILL RESULT

IN LOSS OF PRECHARGE CAUSING

PRODUCT TO FAIL.

CALIFORNIA PROPOSITION 65 WARNING:

This product contains a chemical known by

the State of California to cause cancer and to cause birth defects or

other reproductive harm. (California Installer/Contractor - California

law requires that this notice be given to consumer/end user of this

product.) For more information: www.amtrol.com/prop65/htm.

Firing Rate

Length of Pipe Connecting

of Boiler

Tank to System:

MBTU/H

Below 11’

11’ – 30’

31’ – 100’

2,000

1/2”

3/4”

1”

4,000

3/4”

1”

1 1/4”

8,000

1”

1 1/4”

1 1/2”

12,000

1 1/4”

1 1/2”

2”

16,000

1 1/4”

2”

2 1/2”

20,000

1 1/2”

2”

2 1/2”

EXPLOSION HAZARD. FAILURE TO FOLLOW INSTRUCTIONS IN THE ACCOMPANYING PRODUCT MANUAL CAN CAUSE RUPTURE
OR EXPLOSION, POSSIBLY CAUSING SERIOUS OR FATAL INJURY, LEAKING OR FLOODING AND/OR PROPERTY DAMAGE.

Location of EXTROL

®

Expansion Tanks

DO NOT LOCATE THIS PRODUCT WHERE

LEAKING OR FLOODING COULD CAUSE DAMAGE

TO THE SURROUNDING PROPERTY.

The AMTROL

®

expansion tank may be placed in any convenient position within

the mechanical room (or building). If multiple tanks are installed, they should all

be on the same level.

Point of Connection

Unlike a conventional tank, the EXTROL

®

sealed air cushion does not require

replenishment so DO NOT connect to an air separator or other air collection

device.

As with any expansion tank, it is recommended that the EXTROL

®

be connected

to the suction side of the pump. This will prevent the pump head from becoming

subtractive which may result in entry of air and vapor formation at high points in

the system.

By connecting the EXTROL

®

on the boiler return, displacement of coolest system

water into tank is ensured reducing energy waste.

Low pressure drop components such as air separators and boilers may be placed

between point of connection and pump suction if desired. System design will

dictate the feasibility of this.

Natural convection losses and the entry of air into tanks are eliminated by

connection to the side or underside of main pipe. The piping should be pitched up

and away from the EXTROL

®

to eliminate any potential air traps.

Installation

THIS PRODUCT MUST BE INSTALLED BY A

QUALIFIED PROFESSIONAL.

1. Note location of system connection, air charge valve and drain connection on

tank.

2. Remove the plug or pipe cap from the system connection.

3. Remove the 1 1/2” NPT plug covering the air charge valve.

4. Before making any connection to the tank, check the tank and air charge (use

an accurate pressure gauge). The air pressure must be equal to the minimum

system pressure at the tank location.
