Installation Instructions RSM Elite Series Projector Mounts
3
DIMENSIONS
5.07
128.7
1.83
46.4
ROLL ADJUSTMENT POINT
4
1.61
40.9
1.61
40.9
2.18
55.4
4.37
110.9
.22
5.6
2.28
BOLT CIRCLE
57.8
THREADS ONTO 1-1/2' NPT
YAW ADJUSTMENT POINT
10
PITCH ADJUSTMENT POINT
15
INTERFACE LOCKING SWITCH
NOTE: CUSTOM INTERAFCE BRACKET
NOT SHOWN. THE CUSTOM INTERFACE
BRACKET NEEDED FOR YOUR PROJECTOR
WILL ADD DEPTH TO INSTALLATION AND
THE MOUNT.
SEE SSM-XXX DRAWING ALSO.
