CHIEF RPAA1 - Manual (Page 5)

Installation Instructions RPAA1, B1, C1
5
TOOLS REQUIRED FOR INSTALLATION
PARTS
3/32" (included)
5/32" (included)
R (4)
S (1)
5/32"
U (4) V (4)
T (8)
Q (1)
[RPAX1]
[security box leg]
[spacer]
[washer] [adhesive washer]
A (4)
#10-24 x 1/4"
B (4)
M3 x 10mm
C (4)
M4 x 10mm
D (4)
M5 x 12mm
E (4)
M6 x 12mm
F (4)
1/4-20 x 1/2"
G (4)
M2.5 x 10mm
H (4)
M3 x 10mm
J (4)
M4 x 10mm
K (4)
M5 x 12mm
L (4)
M6 x 12mm
O (1)
3/32"
M (4)
M4
N (4)
M6
P (4)
[thumb nut]
