TRANSDUCER POSITIONING

Refer to drawing Nr. 21566

Drill holes on the machinery for the sensors support and for any cable protection

devices (sheaths, ducts etc.).

2) Drill a hole to fasten the converter box at a distance from the machinery shorter

than that of the connecting cable (5m).

3) Separate the sensors from the converter by disconnecting the cable from the terminal

board inside the converter (carefully note the polarity of the two leads making up

the cable), then mount the sensors on the support prepared in point 1

4) After checking that the machinery lies in position K (ZERO position with the

machine stationary), perform a preliminary mechanical adjustment of the sensors GAP

by acting on the nut-lock nut device of the sensor. The GAPS indicated in the

application drawing refers to the mid point of the measuring range of the

transducer. In the case of frontal measurement of the displacement, the mid point of

the measurement range of the sensors corresponds also to the mid point of the

measurement to be made. If the measurement is longitudinal (sliding of an inclined

block) instead of frontal, proceed to calculate the GAPS corresponding to the

position K of the machinery, taking due consideration of the measuring range and

angle of inclination of the block.

5) Fasten the converter box using the holes drilled in point 2 and attach any

protective sheaths if necessary. Reconnect the sensors cable to the converter

terminal board making sure of the exact polarity of the leads making up the cable.

6) Proceed to the electrical connection of the converter with the measuring

instrument.

The following instructions refer to the machinery under the supply, with the machine

in position K and with the measuring instrument operating, use the nut-lock nut

device of the every sensor to search for the exact coincidence between the

mechanical GAP and the electrical calibration of the converter in the following

way:

- reading on a voltmeter connected across pins A and D of the converter connector

(or else across the terminals corresponding to the transducer signal input on

the terminal board of the instrument) on the scale 0 to 10 Vdc of the range of

measurement (0Vdc= scale start, 10Vdc=full scale) of the volts corresponding

to the Gap; as the Gap indicated in the application drawing of the transducers

refers to the mid point of the range of measurement, under this condition there

should be a corresponding reading of 5 Vdc.

Hence the sensor position should be adjusted through small displacements along its

longitudinal axis until the value of 5 Vdc on the voltmeter.

8) Then lock the sensors in position using the nut-lock nut device.

9) Close the converter making sure that it is spray- and dust-proof.

REMARKS REGARDING CORRECT POSITIONING OF TRANSDUCERS T-NC/S

1) Never, under any circumstances, modify the sensor / converter cable length: this

would cause a measuring error.

2) The end part of the sensor must lie at a distance from metal materials different

from the one involved in measuring the distance: at least twice the max. amplitude

of measurement (see application drawing).

3) When mounting the sensor, a reference cone should be prepared at 90° vertex from

the sensor tip. No metallic material must be introduced in the cone apart from the

surface to be measured.
