PRINCIPLE OF OPERATION
The T-NC system generates a radio frequency field which is radiated by the sensor
surface.
When the reference surface facing the sensor is invested by such RF field, an eddy
current is generated on it. The energy required to generate such eddy current (which is
proportional to the distance between the reference surface and the sensor surface)
reduces, in proportion, the energy present in sensor. Such difference is then detected
by the converter.
The converter amplifies and processes this signal thus supplying a d.c. output voltage
proportional to the distance under consideration.
TECHNICAL CHARACTERISTICS
Composition : sensor, converter
Type of measurement : differential
Range of measurement : ± 6,5 mm
Range of application : Temperature (Sensor) = -20°C to +175°C
Temperature (Converter) = -10°C to +70°C
Humidity (Sensor) = max 100%
Humidity (Converter) = max95% with condens
Ambient (Sensor) = IP67 EN 60529/10.91
Ambient (Converter) = IP65 EN 60529/10.91
Sensitivity : 0.77 V/mm
Power supply : + 15÷24 Vdc; GND.
Connection : Connector MIL C-5015, series 3102/16, standard kit
Convert. casing material : Die-cast aluminium
Sensor casing material : Stainless steel
Weight of the converter : ~ 0.7 Kg
Weight of the sensor : ~ 0.5 Kg
Maintenance : None
Drawings enclosed : 19457 = Overall dimensions, mounting, connections.
