MASTER VOLUME
POWER SWITCH
POWER INDICA
TOR
AC POWER INLET
FUSE 250V1A
LEVEL CONTROL
BASS CONTROL
TREBLE CONTROL
GAIN CONTROL
Ch1 Input
For general high impedance instrument (ex:electric guitar)
Ch2 Input
For low impedance and balanced signal (ex: microphone) For general low impedance signal
Ch3 Input
For low impedance line-out signal (ex: CDP
or MP3)
For general low impedance signal
AIR VENT
LINE OUT
For connect with a recorder or one more PMA3
CONTROL
P
ANEL
