21
4.2 Optional Fans
One: The One includes mounts for up to three more fans. These mounts are as follows:
- 1 x front intake 120 mm mount
- 1 x side 120 mm mount
- 1 x bottom 120/140 mm mount
One S / One S3: The One S / One S3 includes mounts for up to four more fans. These mounts are as
follows:
- 1 x front intake 120 mm mount
- 1 x side 120 mm mount
- 1 x bottom 120/140 mm mount
- 1 x rear 120 mm mount
Front intake 120 mm fan
1. Remove the front bezel as outlined in Section 2.2.
2. Align the fan with the screw holes and screw in the
fan in the top-left and lower-right holes (as pictured).
3. Screw in the long fan screws (E in Section 1.3).
Side 120 mm fan
On the left panel, there is a 120 mm fan mount for additional
graphics cards cooling.
1. Remove the left side panel as outlined in Section 2.2.
2. Align your fan with the mounting holes. The fan
should be installed with air blowing into the case.
3. Screw in the fan with the included screws (H in
Section 1.3).
Screw the side fan into place by first aligning it with
the fan screw holes.
Screw in the fan in the top-left and lower-right holes.
