Drawing 2 of 4 - case assembly – Castle TSM-21 Serial 61076 to 62480 Assembly Drawing & Parts User Manual
Page 4
Page 1
Item #
Part #
Part Description
Qty
Item #
Part #
Part Description
Qty
1
Clamp Cylinder
7
Case Left Side Assembly
P00215
Cylinder,Spring Return,2" Bore,1.5" Stroke,SS Rod
1
U21003
Case Left Side, Green
1
P14414
Fitting, 1/4 NPT x 1/4 Push in Elbow
1
F14340
Carriage Screw, 1/4-20 x 3/4 ZP
2
F01420
Nut, Nylon Lock, 1/4-20 ZP
2
2
H10138
Washer, Fiber, 1-3/8 ID
1
S21001
Label, TSM-21 Model Number
1
S00320
Label. Serial Number
1
3
Clamp Guard
S13264
Label,Electrical Hazard
1
M00210
Clamp Guard, Yellow
1
F14234
Carriage Bolt, 1/4-20 x 1-3/4 ZP
1
8
Dust Hole Cover
F14478
Scrw, Skt Hd Cap, 1/4-20 x 7/8 Bk Oxide
2
M21009
Dust Hole Cover
1
F14202
Nut, Pem Self Clinching, 1/4-20 #2
2
F87192
Screw,PanPhillipsMachine,8-23x3/8 ThrdCutting
3
F01410
Washer, 1/4 SAE ZP
2
F01420
Nut, Nylon Lock, 1/4-20 ZP
3
9
C00010
Front Door Assembly
M00400
Door, Front, Black W/ Logo
1
4
F11212
Nut, Hex Jam 1-1/2-12 ZP
1
10
D00720
Hinge, Plastic, Black, Female
2
F10011
Screw, Hex Washer Head , 10-24 x 1/2 ZP
4
5
C00200
Clamp Foot Assembly
11
D00710
Hinge, Plastic, Black, Male
2
N21351
Clamp Foot, Small Zinc Plated
1
F10011
Screw, Hex Washer Head , 10-24 x 1/2 ZP
4
N70118
Pad, Polyurethane 1-1/8"
1
F12222
Nut, Hex Jam, 1/2-20 ZP
1
12
Case Bottom Assembly
6
Case Top Assembly
U21001
Case Bottom, Green
1
C00210
Face Plate, w/ Adhesive
1
F14584
Carriage Screw, 1/4-20 x 5/8 ZP
4
U21002
Case Top, Green
1
F01420
Nut, Nylon Lock, 1/4-20 ZP
4
F14584
Carriage Screw, 1/4-20 x 5/8 ZP
4
F38034
Carriage Screw, 3/8-16 x 3/4 ZP
3
F14234
Carriage Bolt, 1/4-20 x 1-3/4 ZP
1
F38160
Nut, Nylon Lock, 3/8-16 ZP
3
F01420
Nut, Nylon Lock, 1/4-20 ZP
5
F12120
Washer, 1/2 SAE ZP
2
F08012
Screw,PanPhillipsMachine,8-32x1/2 ZP
1
F08032
Nut, Nylon Lock, 8-32 ZP
1
D08320
Cable Tie Holder, Small White, Nylon
1
13
Case Right Side Assembly
S00301
Label,Warning,Keep Hands Clear,Lexan
1
U21004
Case Right Side
1
S11635
Label, Made in USA
1
F14340
Carriage Screw, 1/4-20 x 1/2 ZP
2
S17578
Label, Caution, "Wear Safety Glasses"
1
F01420
Nut, Nylon Lock, 1/4-20 ZP
2
Drawing 2 of 4 - Case Assembly
21PartsList-Parker 2of4(1).xls
Revised-4/7/2006
