Castle TSM-21 Serial 62481 to 64233 Assembly Drawing & Parts - Manual (Page 7)

Drawing 3 of 4 - Carriage Assembly
Item # Part # Part Description Qty Item # Part # Part Description Qty
1 E27301 Drill Motor, P-C #7301 Laminate Trimmer 1 8 Extension Spring Assembly
2 B00964 Castle Drill Bit, 9/64 Cobalt w/ 1/4" Shank 1 H25061 Spring, Extension, .562 OD x 8.25 L x .062 Dia. ZP 1
D14100 Clevis Pin, 1/4 x 1 1
3 B00038 Rough Mill, 3/8 Dia.Four Flute Cobalt-RM-38 1
9 Bearing Jack Assembly
4 D50038 Collet Assembly, 3/8 PC #6902 1
M21044 Bearing Jack, ZP 2
5 E26902 Router Motor, P-C #6902 1-1/2 HP 1 F14340 Carriage Screw, 1/4-20 x 3/4 ZP 4
F01420 Nut, Nylon Lock, 1/4-20 ZP 4
6 Motor Mount U-Bolt Assembly
10 H00141 Bar Knob, Black Plastic, 1/4-20 2
N21142 Motor Mount U-Bolt, 1/4-20 ZP 1
F01420 Nut, Nylon Lock, 1/4-20 ZP 1 11 Motor Carriage Assembly
F01410 Washer, 1/4 SAE ZP 1
G21122 Motor Carriage Weldment, Yellow 1
7 C21005 Drive Cylinder Assembly N03442 Bushing, 3/4" Hex Carriage Pivot, Brass 2
F42114 Screw, Cup Point Socket Set, 1/4-20 x 1-1/4 3
P21306 Cylinder, 1.06 Bore x 3" Stroke, SS Rod 1 F01420 Nut, Nylon Lock, 1/4-20 ZP 2
D07130 Rod Clevis, 1/4" 1
D14034 Clevis Pin, 1/4 x 3/4 ZP 1 12 Foot Switch Assembly
D14934 Hairpin, 1/4 ZP 1 E00491 Foot Pedal, Linemaster 491-SC36 w/Cord 1
F01424 Nut, Jam, 1/4-20 ZP 1 E07041 Microswith for foot pedal 1
P00535 1/8 NPT x 5/32 PI Swivel Elbow 2 M00235 Guard, Castle Universal Footswitch 1
F40388 Screw, Oval Head Self-Tapping, #4 x 3/8 SS 2
