Case assembly - drawing 4 of 4 – Castle TSM-21 Serial 64234 and above Assembly Drawing & Parts User Manual
Page 8
Item # Part #
Part Description
Qty
Item # Part #
Part Description
Qty
1
Transformer Assembly
8
Control Valve Assembly
E11424
Transformer, 120V Primary, 24V Secondary
1
P21224
3 Way Poppet Solenoid Valve, 24 VDC,
3
D81614
Spade Lug, 16-14 AWG #8
2
P14018
Legris 1/8 NPT x 1/4 PI-EL-SW
2
F63238
Screw, Pan Phillips Machine, 6-32 x 3/8 ZP
2
P00535
1/8 NPT x 5/32 PI Swivel Elbow - Legris
4
F63260
Nut, Lock Washer, 6-32 Kep ZP
2
P00018
1/8 NPT Brass Muffler/Breather
3
P53218
Tubing, 5/32 OD x 3/32 ID Black Polyethelene
48"
2
Control Board Assembly
P53118
Tubing, 5/32 OD x 3/32 ID Natural Polyethelene
44"
E21024
EL-21 Solid State Control Board
1
S12043
Spiral Wrap, 1/2" Black Polyethelene
32"
E21016
Terminal Strip, 16 Pin
1
F63212
Screw, Flat Hd Phillips, Machine, 6-32 x 2-1/2 ZP
2
H00015
Circuit Board Support
3
F63260
Nut, Lock Washer, 6-32 Kep ZP
2
E22708
Wire, 22AWG, 2 Strand, Grey Jacketed
22"
E22708
Wire, 22AWG, 2 Strand, Grey Jacketed
32"
9
D01531
Panel Nut, Metal
1
E22708
Wire, 22AWG, 2 Strand, Grey Jacketed
54"
10
Control Panel Enclosure Assembly
3
H30843
Plate, Power Switch On/Off
1
M21014
Control Panel Enclosure, 14 GA Egalv
1
F14212
Carriage Screw, 1/4-20 x 1/2 ZP
2
4
F75702
Nut, Power Switch Mounting
1
F01420
Nut, Nylon Lock, 1/4-20 ZP
2
E21143
Power Cord, 14-3 SJT w/ 3 Prong Plug
1
5
E75762
Switch, Power, 30 A, 125 VAC
1
D81614
Spade Lug, Vinyl, 16-14 AWG # 8
3
6
Regulator Assembly
11
Motor Power Outlet Assembly
P14113
Regulator, Parker, 1/4 NPT, 0-125 PSI
1
E00000
Outlet, Duplex
1
P12447
1/4 x 5/32 PI Swivel Elbow
1
E96184
Wire. 20AWG Stranded, Green
10"
P25421
Nipple, 1/8 NPT Hex Close
1
E96183
Wire, 14AWG Stranded, Red
10"
P18230
Fitting, 1/8M x 1/8 Barb, White Nylon Elbow
1
F63238
Screw, Pan Phillips Machine, 6-32 x 3/8 ZP
2
P01418
Tubing, 1/4 OD x 1/8 ID, Black Polyurethane
6"
F63260
Nut, Lock, 6-32 Kep ZP
2
P53202
Tubing, 5/32 OD x 3/32 ID Black Polyethelene
6"
P53293
Tubing, 5/32 OD x 3/32 ID Clear Polyethelene
6"
12
Slot Cover Assembly
M00130
Back Plate Slot Cover
1
7
Router Speed Control Assembly
S11436
Tape, PVC Foam S/A 1-1/4"
6"
P00117
Valve, Flow Control, SMC NAS-2000-N01
1
F63210
Screw, Pan Phillips Machine, 6-32 x 1/2 ZP
4
P00535
1/8 NPT x 5/32 PI Swivel Elbow
1
F63260
Nut, Lock, 6-32 Kep ZP
4
P53202
Tubing, 5/32 OD x 3/32 ID Black Polyethelene
6"
CASE ASSEMBLY - Drawing 4 of 4
CASTLE, INC.
TSM-21 OWNERS MANUAL - PARTS LIST
SERIAL # 64324 and Above
