ASSEMBLY COMPONENTS
Items Included In Hardware Box
Part #
Part #
ASSEMBLY INSTRUCTIONS
1-HARDWARE BOX
11FT-RUBBER BASE
100283
16-SCREWS, 6X1/2” PTH SS
100064
4-NUT, HEX 5/16-18 STEEL
100044
1-SINK OUTLET/STAINER
100055
4-CARRIAGE BOLT 5/16X4-1/2
100447
1-SINK TRAP, PLASTIC ADJ
100056
4-WASHER, 5/16 FLAT
100451
1-SINK STOPPER 1 1/2 BLK
100112
12-SCREW, #10X1-1/2 PHIL TR.
100495
4-CLEAT, RAIL
100355
2-ELECTRICAL BOX, 3X2X2.5
100033
16-SCREWS, 8 X 3/4” PHIL
100649
2-GFI ELECTRICAL OUTLET
100034
8 - SHELF CLIPS
100027
8-SCREW, 6X1/2
100475
1-SILICONE SEALANT
100711
2-ROD SOCKET ASSEMBLIES
206505
2-APRON, W/COMP
206802
4-STAINLESS STEEL CORNERS
100057
2-FILLER,BASE 35X13
BF3513KRC
2-FIXTURE, L65-WSA-DIV
100074
2-LEGS FOR WINGS
L36
1-EPOXY SINK, L3 BLK
100691
1- EPOXY TOP, 48X66
100500-F2
2 - SHELVES, 22.188 X 14
200397-2218 2-LEG HARDWARE ASSY
206618
BOOT, LEVL, T-NUT
REV DESCRIPTION
DATE INITIAL
---
Original Created
2-14-07
JWD
