All-Flo SB-10-X44 1 All-PũR - Manual (Page 2)

AIR FLOW CONTROL
VALVE IS OPTIONAL
(USE TO MAINTAIN
MAXIMUM AIR
EFFICIENCY)
AIR FLOW CONTROL
VALVE PART NO:
13408-51
Muffler (air exhaust)
is supplied with
each pump.
DISCHARGE
SUCTION
Flexible Airline
SUCTION AND DISCHARGE PORTS
CAN BE REPOSITIONED TO SUIT
THE APPLICATION
0
DISCHARGE FLOW-Liters / Min.
23
20
(1,3)
PRESSURE INLET/OUTLET PSIG (BAR)
10
DISCHARGE FLOW-U.S. Gals./Min.
20
40
30
AIR CONSUMPTION - SCFM
40
(2,7)
60
(4,1)
80
(5,4)
100
(6,8)
120
(8,2)
0 6 12 18 24 30 36 42 48
45 68 91 114 136 159
T
O
T
A
L
HEAD IN FEET (METERS)
230
(69,9)
184
(55,9)
138
(41,9)
92
(27,9)
46
(13,9)
DIMENSIONS
Dimensions in inches and (mm)
PERFORMANCE CURVE
(Based on water-flooded suction)
SPECIFICATIONS
CAPACITY:
Adjustable 0-41 GPM (155,8 LPM)
MAXIMUM TEMP:
Metallic models – 200˚F (93˚C)
MAXIMUM AIR PRESSURE:
120 psi (8,2 bar)
MINIMUM AIR PRESSURE:
20 psi (1,3 bar)
DRY LIFT:
Models with PTFE balls – 10 feet (3 meters)
Other models – 15 feet (4,5 meters)
WEIGHT:
Aluminum models – 23 pounds (10,5 kg)
Stainless Steel models – 45 pounds (20,4 kg)
MAXIMUM SOLIDS:
1/4˝ (6,2 mm) Ball Check Valve
AIR SUPPLY:
Inlet – 1/4 ˝ NPT Female (BSP compatible)
Outlet – 3/8 ˝ NPT Female
FLUID INLET/DISCHARGE:
Metallic models – 1˝ NPT
DO NOT USE AIR LINE LUBRICATION
Typical Installation
2.09
(53,1)
1.31
(33,3)
1.44
(36,6)
12.00
(304,8)
DISCHARGE
6.00
(152,4)
SUCTION
0.34
(8,64)
3.38
(85,9)
6.76
(171,7)
7.80
(198,1)
AIR
SUPPLY
4.75
(120,7)
4.12
(104,6)
5.00
(127,0)
11.87
(301,5)
12.65
(321,3)
6.87
(174,5)
AIR
EXHAUST
8.88*
(225,5)
7.31
(185,7)
