3 RLB-325 Flat / Incline Ladder Bench
Step 2 Assembly List
Item # Description Qty.
5 ADJUSTABLE REAR SUPPORT 1
7 BACK PAD FRAME 1
8 METAL HINGE 2
19 HEX HEAD CAP SCREW 1/2-13 X 5 1/2 1
20 HEX HEAD CAP SCREW 1/2-13 X 8 1/2 1
22 FLAT WASHER SAE 1/2” 2
26 NYLON INSERT JAM LOCK NUT 1/2-13 2
Step 3 Assembly List
Item # Description Qty.
4 ADJUSTABLE FRONT SUPPORT 1
6 SEAT PAD BRACKET 1
12 SEAT PAD 1
13 BACK PAD 1
16 HEX HEAD CAP SCREW 3/8-16 X 1 1/4 6
18 HEX HEAD CAP SCREW 1/2-13 X 3 3/8 1
22 FLAT WASHER SAE 1/2” 2
23 FLAT WASHER SAE 3/8” 6
26 NYLON INSERT JAM LOCK NUT 1/2-13 1
