Rhe-340 parts list, 7rhe-340 adjustable hyper extension bench – Tuff Stuff RHE-340 Adjustable Hyper Extension Bench User Manual
Page 7
REV0
ITEM
DESCRIPTION
REV
PART NO.
QTY
ITEM
DESCRIPTION
PART NO.
QTY
1
BASE FRAME
0
UP3902
1
24
TURN/PULL PIN W/KNOB AND LOCK
BNH0989
2
2
ADJUSTMENT TUBE HOUSING
0
UP3903
1
25
SOCKET SET SCREW ALLOY 10-32 X 1/8
BNH0473
4
3
ADJUSTMENT CHROME TUBE
0
UP3904
1
26
BRONZE BUSHING 1/2 X 5/8 X 1/2 X 7/8 X 1/8
BNH0528
6
4
ABDOMEN PAD SUPPORT
0
UP3905
1
27
FOAM FOOT ROLL 1 X 4 X 7 W/VINYL
UP3785
4
5
TOP SUPPORT
0
UP3906
1
28
NYLON INSERT LOCK NUT Z/P 1/2"
BNH2026
3
6
UPRIGHT FRAME
0
UP3907
1
29
NYLON INSERT JAM LOCK NUT Z/P 3/8-16
BNH2026
8
7
SLOPE SUPPORT
0
UP3908
1
30
FLAT WASHER SAE Z/P 3/8"
BNH2030
24
8
FOOT SUPPORT
0
UP3909
1
31
FLAT WASHER SAE Z/P 1/2"
BNH2031
6
9
RUBBER GRIP 1 ID X .125 X 6
BNH0960
2
32
SPLIT LOCK WASHER Z/P 3/8"
BNH2032
8
10
LEG HOLDER
0
UP3910
1
33
BUTTON HEAD SOCKET CAP SCREW Z/P 3/8-16 X 1
BNH2033
4
11
SAFETY TAPE ANTI-SLIP 4 X 12
BNH2024
2
34
HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1
BNH2037
6
12
ABDOMEN PAD RIGHT SIDE
0
UP3911
1
35
TUFFSTUFF LOGO ALUMINUM SMALL
BNH1323
1
13
ABDOMEN PAD LEFT SIDE
0
UP3912
1
36
HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 3/4
BNH2040
4
14
FOAM ROLL 1" NYLINER BUSHING
BNH2025
8
37
HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 3/8
BNH2043
4
15
ALUMINUM WASHER .390 ID X 1.500 OD X .150 THK
BNH1541
4
38
HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3
BNH2046
2
16
BLACK WHEEL 3/8 X 3 X 1 1/4 W/BEARING
BNH0300
2
39
HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 3 3/8
BNH2047
2
17
PLASTIC HORIZONTAL ELLIPTICAL SHOE
BNH1847
4
40
HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 5 5/16
BNH2048
1
18
ALUMINUM CAP 1.020" RD (CAP-100)
BNH0537
2
41
HEX HEAD CAP SCREW GR-5 Z/P 5/18-18 X 3/4
BNH2049
2
19
PLASTIC INSERT ELLIPTICAL GUIDE (2X4)
BNH1760
1
42
FLAT PHILLIPS MACHINE SCREW 8-32 X 1/4
BNH0408
2
20
PLASTIC INSERT CAP ELLIPTICAL 1 1/2 X 3
BNH1795
1
43
FLAT PHILLIPS SCREW ZINC # 2 X 1/2
BNH1480
2
21
PLASTIC TUBE GLIDE 2 X 1 X 8
BNH1874
2
44
HEX KEY ALLOY 3/32"
BNH0372
1
22
PLASTIC INSERT CAP 1 1/2" SQ 10-14 GA
BNH0009
2
45
HEX KEY ALLOY 7/32"
BNH0575
1
23
PLASTIC INSERT CAP ELLIPTICAL 2 X 4
BNH1794
1
46
LITHIUM GREASE SMALL CONTAINER
BNH0705
1
RHE-340
Parts List
COLOR CHART
BOLD FONT = SUB-ASSEMBLY PARTS
BLACK= HARDWARE
7
RHE-340 Adjustable Hyper Extension Bench
