MoTeC Specifications
5
Specifications
Electrical
Power Supply Voltage
14V Nominal (5V to 18V)
Power Supply Current
100mA (at 14V input), 270mA (at 5V input)
Connections
Pinout for 3 pin Adapter Cable
Mating Connector
Deutsch DTM06-3S
Pin Name Description
1
Bat -
Connect to Battery Negative on the logging device
2 TX Connect
to
RX
pin on logging device
3
Bat+
Connect to Battery Positive on the logging device
Pinout for 9 pin Connector on GPS Unit
Pin Name Description
1
Bat +
Connect to Battery positive on the logging device
2
RX
Don't Connect (Only used for programming)
3 TX Connect
to
RX
pin on logging device
5
Bat -
Connect to Battery Negative on the logging device
Data
Output Type
RS232
Output Levels
+/- 6V (nominal)
Baud Rate
57600 (Motec default)
NMEA Sentences
RMC, GGA (Motec default)
GPS Unit Physical
Size
91 x 76 x 25mm (3.6 x 3.0 x 1.0in) (LxWxH)
Weight 105g
(3.7oz)
Operating Temp
-30C to +70C (-22 to 158F)
