Adjustment
Tiller Angle Adjustment
The Tiller Adjustment lever is located
on the side near the bottom of the
tiller. To adjust the tiller angle, hold
onto the handlebar with one hand to
support its weight, pull the tiller
adjustment lever outwards and
adjust the angle of the tiller to the
desired position. When you are
comfortable, tighten the lever once
more.
IMPORTANT! Do not drive the
scooter if the tiller is not secured.
Seat Adjustment
You can adjust the seat to be either
closer or further from the tiller. The
seat adjustment lever is located on
your seat to the left hand side where
your left leg rests. To adjust your
seating distance, simply lift the lever
and adjust your seat accordingly.
Once released, the seat will
automatically lock into place.
Tiller Adjustment Lever
Seat Adjustment Lever
Tiller Adjustment Lever
Seat Adjustment Lever
