7
SK51102 ver. A0
User’s Manual
www
.chenbr
o.com
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: [email protected]
Introduction
The CHENBRO SK51102 can house one Hot-swap 2.5” SATA HDD in one slim ODD bay converter. The ability
for conversion allows existing server or PC to perform with one Hot-swap HDD and keep the flexibility.
In all, SK51102 is the best solution as value added feature and performance.
Functional Specification
General
z Support up to SATA-II (3.0 Gb/s)
z Compatible with 2.5” SATA HDD (9.5 mm height)
z Support inrush current control for HDD Hot-swapping
z LED indicate activity and failure
Host / Drive / Power Backplane Interface
z 1 to 1 connection for 2.5” SATA HDD
z 1x SATA / SAS Signal + Power (7+15 pin) connector at HDD side of backplane
z 1 x SATA / SAS interface (7 pin)
z 1 x DC power connectors (4-pin FDD power connector)
SK51102 supports 9.5 mm high 2.5” HDD only
The HDD activity LDE is available for SATA-II HDDs.
If SATA-I HDD applied, the HDD activity LED will not work.
