Page 6
6
SK32303 ver. A1
User’s Manual
www
.chenbr
o.com
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: [email protected]
Getting Start with the SK32303 Storage Kit
Thank you for purchasing SK32303! This section covers unpacking and identifying components.
Unpacking and Checking the Contents
The complete SK32303 package includes the following items:
Item Description
Quantity
SK32303 Storage Cage
1
Hot-swap 3.5” Hard Disk Drive (HDD) Tray
3
SAS / SATA-II cable
3
HDD failure / activity signal Cable
1
Screw: #6-32 (6mm) for tray and HDD assembling
12
Screw: M3 (6mm) for Storage Cage and chassis assembling
6
The HDD failure / activity signal cable (26H113215-005) is available for using on
HDD failure or activity LED.
Refer to the RAID card user manual for the detailed application and connection
information.
Technical Specifications
Occupancy
2 x 5.25” Drive Bays
Capacity
3 x SATA-I, II or SAS Hot-swap HDDs
Cooling Subsystem
1 x 60mm (Thickness 25mm) Exhaust Fan
System Monitoring
Fan Failure LED and Alarm
Overheat LED and Alarm
HDD Failure LED and Alarm
Dimension (WxHxD)
146 x 84.5 x 218.7 (mm)
5.75 x 3.32 x 8.61 (inch)
Weight (fan included)
1.4 kg
Compatible CHENBRO Chassis
z RM21600 / RM31300 / RM31408
RM41100 / RM41500 / RM42200
z SR105 / SR107 / SR108 / SR201 / SR209
z PC617
