4-Port SAS / SATA to Mini-SAS 6G Backplane 80H10220918A0
User’s Manual
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: [email protected]
www
.chenbr
o.com
Backplane Specification
Hardware Specification
Host Interface Mini-SAS
HDD Interface SAS (22+7) and SATA compatible
Hot-Swap Yes, allows user to replace Hard Disk Drive (HDD) on line
Display
LED indicates HDD status (Defined by Chenbro)
Power LED – Blue ( When HDD is present )
Access LED –Green (When HDD is busy )
Error indicator – Red (Error when retreating signals )
Cooling Two Fan connectors
Environment Monitor Fan speed and temperature detect
Connectors
Mini-SAS x1 to host
SAS (22+7) x4 ( for HDD )
Standard 4P Power connector x 2 (+5V & +12V from power supply)
Dimensions 114.8 (Length) x 107.8 (Width) x 2.4 (Thickness) mm
Accommodated Chassis
This backplane can be applied to the Chassis as below:
z SR105 / SR107 / SR108 / SR209
