Chenbro RM91250 3Gb/s 4-port 3.5 mini-SAS Backplane(80H10321513C0) Rev.C0 - Manual User Manual
Page 20
4-Port Mini-SAS Backplane 80H10321513C0
User’s Manual
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: [email protected]
20
www
.chenbr
o.com
Example for RM41416B Mini-SAS backplane wiring
HDD16 HDD15 HDD14 HDD13
HDD12 HDD11 HDD10 HDD9
HDD8 HDD7 HDD6 HDD5
HDD4 HDD3 HDD2 HDD1
Mini-SAS cable
LED board signal
cable
Chassis fan wiring
(Connecting start from
Fan1)
LED Board
Chassis Fan x5
HBA/RAID Card
