4-Port SAS / SATA-II Backplane 80H103314-002 ver. A1
User’s Manual
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: [email protected]
www
.chenbr
o.com
Chassis Assembly Example
See below for the example of how the wiring to be performed.
Example for RM31408 chassis SATA backplane wiring
Ordering Information
HDD Cage with Backplane - Bulk Packing Part Number List
Part No.
Description
Chassis Model
84H331410-009 HDD Cage with SAS/SATA-II, 4-port Backplane
RM31408
SATA cable (BP to Host Adaptor, 4x cables per BP)
Chassis fans wiring (Connection start from Fan1)
2-pin System Failure LED & Alarm Mute Cables (BP to Front Panel LED Display)
LED Cable
SATA RAID Card
Chassis Fan x2
Chassis Fan x2
