6-Port 6Gb/s Mini-SAS Backplane 80H10321711A0
User’s Manual
15Fl., No.150, Jian Yi Road, Chung Ho City, Taipei Hsien, Taiwan R.O.C.,
Tel: +886 2 82265500 Fax: +886 2 82265392 Email: [email protected]
5
w
w
w
.
c
h
e
n
b
r
o
.
c
o
m
6Gb/s Backplane Specification
P/N: 80H10321711A0
Host Interface
2 x Mini-SAS interface (SFF-8087) for host side (w/lock housing), port
distribution should be “4+2”
HDD Interface SAS (15+7+7) and SATA-II (15+7)compatible with 3.5” HDD
Hot-Swap Hard drives can be replaced during the system on
Display
LED indicates HDD status (Defined by Chenbro)
Power LED – Blue light (HDD is on)
Access LED –Green flash (HDD is working)
Error indicator – Red light (HDD is abnormal)
Cooling 3-pin fan connector x 4
Power Connector Standard +5V and +12V 4-pin power connector x 2
Other Connectors
2-pin power alarm connector x 1
2-pin alarm mute connector x 1
6-dip function switch for monitoring fan and temp
2-dip SGPIO function switch
4-pin HDD fail connector x 2
7-pin function connector for fan fail LED / power mute LED / global mute
switch
Dimension 257.3 mm (Length) x 80.0 mm (Width) x 2.4 mm (Thickness)
Material FR4 6 layer
Accommodation Chassis
RM21706
