BeStar BMS15-11C-08H05RP LF - Manual (Page 2)

H H
王文邦
BESTAR ELECTRONICS INDUSTRY CO.,LTD
Rev. Date
6
A
06/12/08 A
B
BMS15-11C-08H05RP LF
Speaker
www.be-star.com [email protected]
Approved by: Note Drawn
5 4
Drawn by:
Checked by:
Date:
程久生
3 2
DRG NO: BS/TES01.731A
王文邦
高 正
06/12/08
1
Page:1 of 5
A
B
1. Characteristics
1.1 Electrical and Mechanical Characteristics
No. Item Specification
1. Dimension Ø15 x 5 (mm)
2. AC Impedance 8Ω ± 15%at 1.5KHz
3. Rated Input Power 0.5W
4. Maximum Input Power 1.0W
5. Resonance Frequency 850Hz ± 20%
6. Frequency Response F0~12KHz
7. Sensitivity 87± 3dB/0.5W /0.1m at 1,1.2,1.5,2.0KHz average
8. T.H.D Less than<10% at 1KHz/0.5W
9. Buzzes & Rattles Must be normal at sine wave 2.0Vrms
10. Operating Temperature -30~+ 70 ° C
11. Storage Temperature -40~+ 80 ° C
12. Weight 1.3g
T
h
is
p
ri
n
t
and
i
n
fo
rm
a
ti
on
t
he
re
i
n
a
re
p
rop
ri
e
ta
ry
t
o
B
e
s
ta
r E
le
c
tr
on
ics
I
ndu
s
tr
y
C
o
.,
L
td
.
and
s
ha
ll
no
t
be
u
s
ed
i
n
w
ho
le
o
r
in
p
a
rt
w
it
hou
t
it
s
wr
itt
en
c
on
tent
D
C
E
F
G
D
C
E
F
G
6 5 4 3 2 1
BMS15-11C-08H05RP LF
1.2 Test Method
Speaker
Digital Audio Analysis System
Microphone
Audio
analyzer
Power amplifier
10cm
