WireMaster Mole Model R460HA
Parts List
Ref #
Part #
Description
# Req'd
1
450-001
Frame
1
2
450-002
Handlebar
1
3
450-003
Assembly, Rotor Arm with Bearings & Spacer
1
4
450-251
Bracket, Idler Arm
1
5
450-024
Stop, Belt, Engine Pulley
1
6
460-252
Hood, Back Plate
1
7
450-752
Brush
1
8
450-503
Channel, Brush
1
9
991-05
Arm, Idler
1
10
12-22-2A
Pulley, Double Idler
1
11
991-06
Spring, Idler Arm Return
1
12
780-30
Belt, 31" Kevlar, Model R450H Only, 3.5" O.D. Pulley
2
12
450-767
Belt, 33" Kevlar, Model R450HA Only, 4.5" O.D. Pulley
2
13
701-02-2
Pulley, Engine
1
14
230-0002
Stop, Belt
1
15
450-502
Spindle, Rotor w/Nut
1
16
450-501
Pulley, Double Rotor, Model R450H Only, 3.5" O.D.
1
16
450-768
Pulley, Double Rotor, Model R450HA Only, 4.5" O.D.
1
17
450-758
Key, 3/16" x 3/16" x 3/4" Long, Rotor Pulley
1
18
450-751
Bearing, Rotor
2
19
450-004
Bearing, Spacer
1
20
450-765
Washer, 3/4" SAE Rotor Spindle (against each bearing)
2
20A
450-766
Flatwasher, 3/4" (against back of rotor)
1
21
Not Sold Separately
Engine, Honda GX160
1
22
450-259
Clutch Lever, Over Center
1
22
450-504
Lever, Clutch, Black
1
23
701-25
Grip, Handle
2
24
450-770
Cable, Clutch, For over Center Handle
1
24
450-754
Cable, Clutch w/Clevis & Turnbuckle, Black Lever
1
25
701-24A
Spring, Clutch
1
26
12-09
Pin, Sheave w/Cotter Pin
1
27
701-06A
Nut, 5/8" Nylon Lock
2
28
702-27B
Bearing, 5/8" Wheel (2 per wheel)
6
29
702-50C
Wheel, Pneumatic w/ 5/8" Bearing
3
30
702-78
Strap
1
31
460-009
Bracket, Pex, Tube
1
32
460-251
Brace, Outside
1
33
460-501
Drape, Hood
1
34
450-755
Nut, Height Adjuster Wing - 5/8"
1
35
450-764
Bolt, Front Axle - 5/8" x 4"
1
36
460-504
Clip, 12mm
1
37
460-505
Clip, 10mm
1
38
460-002
Rotor, WireMaster
1
39
450-507
Point, Rotor ( 2 1/4" straight)
N/A
40
450-762
Assembly, Front Axle (Bolt, Nuts, Washers & Wing Nut)
1
41
450-025
Stop, Belt, Rotor Pulley, Model R450HA Only, 4.5" O.D.
1
42
450-763
Stop, Idler Arm, 5/16" x 3 1/2 " NF Bolt
1
43
460-503
Knob, Up/Down Adjustment
2
44
460-007
Rod, Ground
1
45
460-008
Bracket, Front, Up/Down
1
46
460-004
Bracket, Drape Retainer
1
47
460-010
Clamp, Wire Spool Bracket
1
48
460-013
Bracket, Wire Spool Mount
1
49
460-014
Tube, Wire Conduit, PEX
1
54
460-252
Hood, Back Plate
1
6 & 33
460-015
Assembly, Hood with Drape
1
