E-104H EdgeMaster
TM
PARTS LIST
REF.
NO.
PART NO.
DESCRIPTION
NO.
REQ.
1
E-100-001
GUARD, BLADE 10”
1
2
12-32A
TIRE AND WHEEL ASSY.
3
3
E-100-003
HANDLE ASSY.
1
4
E-200-002
BELT
2
5
E-100-005
BLADE, EDGER, 10”
1
5A
E200-029-10
BLADE, EDGER, 10” STAR
5B
E200-029-09
BLADE, EDGER, 9” STAR
6
12-02
HANDLE GRIP
2
7
E-100-007
LEVER, BELT TENSIONER
1
8
E-200-008
ROD, BELT TENSIONER CONTROL
1
9
E-100-009
ROD END
2
10
E-200-010
IDLER ARM
1
11
12-22-2
PULLEY, IDLER
1
12
E-100-012
BELT GUARD (FRONT)
1
13
E-200-013
BELT GUARD (REAR)
1
14
E-200-014
BLADE BOLT ASSY.
(1/2” X 8 1/2” Gr. 8 w/ lock nut)
1
15
12-16
SPINDLE BEARING
2
16
780-09
PULLEY, SPINDLE
1
17
E-200-017
SPINDLE ARM
1
17A
E-200-018
BUSHING
1
18
701-02-2
PULLEY, ENGINE
1
NS
E-100-020
DECAL, WARNING
2
NS
E-100-021
DECAL, DANGER
1
21
E-200-023
WHEEL ADJUSTING HANDLE
2
23
E-20-025
RUBBER FLAP
1
24
E-100-026
HANDLE GRIP, LEVER
1
25
E-200-027
SPINDLE
1
26
E-100-031
INNER WHEEL SLIDE
2
27
E-200-032
FRAME
1
28
12-05
SPRING, IDLER ARM
1
29
E-100-036
SPRING, LEVER
1
NS
12-19
1/4” x 1 1/2” KEY, SPINDLE PULLEY
1
NS
E-100-038
3/16” x 1 1/4” KEY, ENGINE PULLEY
1
32
E-100-039
BLADE GUARD CLAMP
1
