No. Item Specifications
1 Sensitivity -52
±3dB(0dB=1V/Pa,1kHz)
2 Frequency Response 100Hz-10kHz
3 Current Consumption 0.5mA Max.
4 Directional Noise Cancelling
5 S/N Ratio more than 58dB
6 Standard Operating Voltage 2V
7 Operating Voltage 1V~10V
8 Sensitivity reduction within -3dB at 1.5V
9 Distortion 2%
10 Storage Temperature -40
°C to +70°C
11 Operating Temperature -30
°C to +60°C
1. Characteristics
Test Condition (Vs=2V RL=2.2K Ω Ta=20℃ R.H.=65%)
★Frequency Resonse Curve
