Sounder
6 5 4 3 2 1
F-B-P3009EPB-01 LF
DRG NO: BS/TEP01.115D
Piezo Sounder
Date:
Checked by:
Drawn by:
Approved by: Drawn
A
Date REV. Note
B
07/11/24
www.be-star.com [email protected]
张秀琴
陶红仲
赵 峥
100mm
400
mm
C
A
Page:1 of 6
B
C
Item Specification
Rated Voltage(Square Wave) 9Vp-p
Operating Voltage 1-30Vp-p
*Rated Current max.5mA
*Sound Output at 10cm ,2500Hz min.91dB
Resonant Frequency 2500Hz
Capacitance at 120Hz 20000 30% pF
Operating Temperature -40...+85 C
Storage Temperature -40...+85 C
Weight 5g
*Value applying at rated voltage.
No reaction in space with in 400mm in all direction
1.2 Test method:
D
E
F
D
E
F
1.1 Electrical and Mechanical Characteristics
G
1. Characteristic:
4 5 6
F-B-P3009EPB-01 LF
H
2 3
G
1
H
D 07/11/24 赵 峥
