Piezo Sounder
Page:2 of 8
No. Item Specification
1. Rated Voltage(Square Wave) 12 Vp-p
2. Operating Voltage 10~60Vp-p
3. a)Rated Current max.30mA
4. Capacitance at 120Hz 180 30%nF
5. a)Sound Output at 2.8KHz,10cm Min.100dB
6. Resonant Frequency 2.8 0.2 KHz
7. Operating Temperature -40...+85 C
8. Storage Temperature -40...+85 C
a)Value applying at rated voltage.(12Vp-p square wave,1/2duty)
Rev. Drawn Date Note
1.2 Standard test Fixture
No reaction in space with in 400mm in all direction
www.be-star.com [email protected]
赵 峥
邱 俊
李红元
赵 峥
BPT6012H15.5W080 LF
BPT6012H15.5W080 LF
100mm
Sounder
40
0mm
1.Description
1.1 The specification relates to the piezoelectric sounder intended to be
used in alarm sysytems. Please contact us before using any of the
products in the applications not described above.
1.2 Electrical and Mechanical Characteristics
A 09/03/28
DRG NO: BS/TEP01.668A
09/03/28
博 士 達
