2. Dimension
Tolerance: 0.3 Unit:mm
BPT2412XH16 LF
1. Characteristics
Electrical and Mechanical Characteristics
E
F
G
H
6 5
E
F
G
4 3 2
H
1
No.
Item Specification
1. Rated Voltage 12V
2. Operating Voltage 3...20V
3. a)Rated Current max.10mA
4. a)Sound Output at 30cm min.90dB
5. a)Resonant Frequency 3700 500Hz
6. Operating Temperature -20...+60 C
7. Storage Temperature -30...+70 C
8. Weight 5 g
a)Value applying at rated voltage
16
2-
0
.8
0
.05
6
23
.8
15
0
.3
BPT2412XH16 LF
Piezo Buzzer
DRG NO: BS/TEP01.046C Page:1 of 4
REMOVE
SEAL
AFTER
WASHING
Masking Label
