Speaker
Page:06 of 09
B
C
B
C
E E
D D
F F
G
4.Bill of Material
H
G
H
6 5 4 3 2 1
DRG NO: BS/TES01.006B
BMS3650L-P2-HT LF
BMS3650L-P2-HT LF
No Parts Name Material
4 Magnet plate SPCC
5 Magnet bowl SPCC
1 Membrance PEI-ULT005V
7 Pin Cu
6 Frame PBT
3 Magnet Magnet N 38H
3
6
1
2
5
4
8
8 Mesh Silk
7 9
9 Potting glue SILICONE LIQUID RUBBER
2 Voice Coil φ0.05 wire,Annealed Copper Alloy
A 王善梅 02/04/27
B 莫丽丽 08.05.14
博 士 達
陶红仲
莫丽丽
王文邦
08.05.14
