Speaker
BMS40-12-08H6.9CW65M LF
DRG NO: BS/TES01.736A
莫丽丽 王文邦
张秀琴
莫丽丽
BMS40-12-08H6.9CW65M LF
2.Drawing
unit:mm
6
.9
±0
.3
Ш15.9±0.3
Ш16.8±0.3
Ш36
Ш40±0.3
≈
Red
Black
2x Wire UL1007 AWG22# ,Colour:Black(b) and red(r)
Connector:Molex 31067-1071
4
.0
±
0
.3
Ø38.9±0.4
Protective
cover
65 ±5
