3.5 Temperature Cycle Test
Cycles 4
Notice:
1.After test leave at room temperature for 1 hours,SPL shall not deviate by
±3dB from pre-test measurement,and meet above spec.item 5,6,7,8,9
3.6 Drop Test
Height 75cm
Drop face free falling on concrete floor
Times 10 times
+25
-40
T( °C)
+85
t hrs) 1
1 cycles
1 1
transition time:20-30s
3.7 Vibration Test
Frequency 30
±15Hz
Amplitude 1.5mm for 3hrs
