Reliability test, 40 c – BeStar BMS3450-02 LF User Manual
Page 6
5.1High temperature test
Temperature +85 C
Duration ≥1000hrs
5.2 Low temperature test
Temperature -40 C
Duration ≥500hrs
5.3 Humidity test
Temperature +40 C
Humidity 90-95%RH
Duration ≥56days
5.4 Temperature cycle durability:
-40 C/+85 C ≥100cycle (1 cycle=4h)
After each test of 5.2-5.5,the sound pressure level requirement must be fufilled.
5.5 Impact resistance:
100g for each three mutually perpendicular directions to each of 3 times by sine-wave:
no damage,no alternation of specified parameters
5.6 Proofness due vibrations:
sine-wave excitation;8...300Hz ,2g,
1 octaves/min; test time 16h each axes
5.7 Noise test :
10 -200Hz: 0.01g2/Hz,acceleration 1 .9g
200 - 1000Hz: -6dB / Oct.
Test time 8h each axes.
5.8.1 Shelf Life :
V
PP
=7.0V rectangle pulse shape, alternating ON for 10 sec./ OFF for 10secs
(equivalent to 180 cycle /h ) low or 1st control frequency is 600 Hz ,high or 2nd control frequecy is 3000Hz
Switch-on time(total) for 1st control frequency : 60h (10800 cycles)
Including 42.5h (7650 cycles) at T
amb
=+20 C
10h (1800 cycles) at T
amb
=+85 C
7.5h (1350 cycles) at T
amb
=-40 C
Switch-on time(total) for 2nd control frequency : 17h (3060 cycles)
Including 9h (1620 cycles) at T
amb
=+20 C
4.5h (810cycles) at T
amb
=+85 C
3.5h (630cycles) at T
amb
=-40 C
After these and the following tests the values of loudness ( 2dB) and sound (distortion)
must be within the specification.
5.8.2 Function of indicator:
Us=6.4V rectangle pulse shape, 10 times on/off, pause for 10sec. according one indicatorphase.(note diagram fig 1)
Total 150000 indicatorphase
Including 100000 indicatorphase at T
amb
=+20 C
25000 indicatorphase at T
amb
=+85 C
25000 indicatopphase at T
amb
=-40 C
