BeStar BMS1813F-11C-08H4.5 LF - Manual (Page 3)

T
h
is
p
ri
n
t
a
n
d
i
n
fo
rm
a
ti
o
n
t
h
e
re
i
n
a
re
p
ro
p
ri
e
ta
ry
t
o
B
e
s
ta
r
A
c
o
u
s
ti
cs
C
o
.,
L
td.
a
n
d
s
h
a
ll
n
o
t
b
e
u
s
e
d
i
n
w
h
o
le
o
r
in
p
a
rt
w
it
h
o
u
t
it
s
w
ri
tt
en
c
on
tent
B
6
A
4 5 3
C
2 1
A
B
C
D
E
F
G
H
6 4 5 3
D
E
F
G
1 2
2.Description
2.1 Acoustic Component Performance Specification
2.2 The present document specifies performance
requirements for the acoustic characteristics of speaker
www.bestargroups.com [email protected]
Drawn Rev. Date Approved by:
Checked by:
Note
Page:03 of 13
3.Characteristics
3.1 Electrical and Mechanical Characteristics
No. Item Specification
1. Dimension 18 x13 x 4.5(mm)
2. DC Resistance 7.8Ω ±15%
3. AC Impedance 8Ω ±15%(at 2KHz/0.5W)
4. Rated Power 0.5W(2.0V/ in 1.0cc box)
5. Maximum Power 0.7W(2.37V/ in 1.0cc box)
6. Resonance Frequency 800Hz ± 15% (in 1.0cc box)
7. Frequency Response F0~20KHz
8. S.P.L 92
±3dB/0.1m/0.5W at 2.0KHz(in 1.0cc box)
9. THD 30% at 600Hz/0.5W
≤10% at 1KHz/0.5W
10. Buzzes & Rattles Must be normal at sine wave 0.89Vrms (in free air)
/2.0Vrms(in 1.0cc box) from 200~3400Hz
11. Polarity Positive voltage to (+),Diaphragm moves forward
12. Operating Temperature -20~+ 70 °C
13. Storage Temperature -20~+ 70 °C
14. Weight ~2.7g ±0.3g
Speaker
BMS1813F-11C-08H4.5 LF
DRG NO: BS/TES01.1230B
BMS1813F-11C-08H4.5 LF
汪珍珍
1.Test Climatic Condition
1.1 Ambient Temperature :15 °C~35°C,Preferably at 20°C
1.2 Relative Humidity:25% to 75%
1.3 Air Pressure:86kPa~106kPa
400Hz ±20% (in free air)
Drawn by:
Date:
B 王凯 王凯
王凯
2013/09/10
2013/09/10
