BeStar BSR16-11C-08H3.8RW016J LF - Manual (Page 2)

H H
Rev. Date
6
A
A
B
Speaker
www.be-star.com [email protected]
Approved by: Note Drawn
5 4
Drawn by:
Checked by:
Date:
程久生
3 2
DRG NO: BS/TESR01.158A
朱成兴
韩学慧
07/04/23
1
Page:1 of 8
A
B
1. Characteristics
1.1 Electrical and Mechanical Characteristics
1. Impedance(at 2kHz) 8±15%Ω
2. Rated Input Power 0.6W
3. Maximum Input Power 1.0W
4. Resonance Frequency 710±20%Hz
5. Frequency Response F0～20KHz
6. Output SPL 89±3dB/0.1W 0.1m at0.8,1.0,1.2,1.5KHz Average
7. Distortion (at 1kHz,0.6W) ≤5%
8. Buzzes & Rattles Dynamic speaker must be free audible noise at 2.19Vrms
sine wave between F 0 and 20KHz frequency range
9. Operating Temperature -30 ～ +70°C
10. Storage Temperature -40 ～ +85°C
T
h
is
p
ri
n
t
and
i
n
fo
rm
a
ti
on
t
he
re
i
n
a
re
p
rop
ri
e
ta
ry
t
o
B
e
s
ta
r E
le
c
tr
on
ics
I
ndu
s
tr
y
C
o
.,
L
td.
and
s
ha
ll
no
t
be
u
s
ed
i
n
w
ho
le
o
r
in
p
a
rt
w
it
hou
t
it
s
wr
itt
en
c
on
tent
D
C
E
F
G
D
C
E
F
G
BSR16-11C-08H3.8RW016J LF
6 5 4 3 2 1
朱成兴 07/04/23
BSR16-11C-08H3.8RW016J LF
Speaker Mode
1. Sensitivity 117±3dB at 1KHz,100mV(odB=20μPa=0.0002μBar)
2. Frequency Response 300～3.4KHz
3. Rated Input Power 30mW
4. Maximum Input Power 50mW
5. Buzzes & Rattles Receiver unit must be free audible noise at 0.49Vrms
sine wave between 300Hz and 3.4KHz frequency range
Receiver Mode
Measured by Artificial Ear IEC-318
