Avlex ACT-30T Bodypack Transmitter - Manual (Page 10)

AUDIO
SHIELD
4
3
2
1
PIN
SHIELD
AUDIO
BIAS
3
4
PIN
1
2
AUDIO
SHIELD
1
4
3
2
PIN
SHIELD
AUDIO
3
2 1
PIN
4
3
2
1
SHIELD
AUDIO
1
3
4
2
PIN
AF Input Connections
(1) 2-Wire Electret condenser
microphone Capsule
(2) 3-Wire Electret condenser microphone Capsule
(3) Dynamic Microphone
(5) Line-in (Impedance 8KΩ ATT. 10dB)
(4) Electric Guitar
1 3
4
2
1 3
4
2
1 3
4
2
1 3
4
2
1 3
4
2
Bodypack Transmitter Bodypack Transmitter
14 15
“PoFF” - Power Off:
When the power switch is turned off, the LCD will
show “PoFF” (for Power Off) first and then the
system will shut down and no further messages will
be displayed.
Battery Status
Indicates the power remaining in the transmitter
battery. When the battery has less than 10% power
remaining it must be replaced or recharged. If an
under voltage condition continues, the LCD will show
“PoFF” and the system will shut down to prevent
being overly discharged.
100% 80% 60% 40% 20% 10%
