User’s Manual
10-1
10. Specifications
All specifications are subject to change without notice.
Model Number: DL-1101S/DL-1103S
Scanner Type: Duplex Scanner (DL-1101S)
Simplex Scanner (DL-1103S)
Scanner Type: Sheet-fed and flatbed
Light Source: LED
Optical Resolution: 600 dpi
Scanning Modes: Black & White
Gray
Color
ADF Capacity: Up to 50 pages (20lbs)
Document Size: Letter, legal, A4, B5, A5
Max. Document Size: 8.5”x14”
Min. ADF Document Size: 2” x 2,5”
Paper Weight (ADF):
7~110 lbs (28~400 g/m 2 )
ID Card Thickness (ADF): Up to 1.25 mm (0.05 inch)
Interface:
Hi-speed USB 2.0
Power Source: 24V, 2.0A
Power Consumption: <36W (operation)
<15W (standby)
<5W (power saving)
Operating Temperature: 10ºC~35ºC
Dimensions: (HxWxD) 588 x 319 x 272 mm
(23.15” x 12.6” x 10.7”)
Weight: Approx. 8.2 kgs (18 lbs)
