7

3. Mounting and adjusting the

camera (Fig.3)

1. Loosen (but do not remove) the fixing

screws of the adjustable hinge with a
suitable Allen key.

2. Place the camera on the support. Use the

screw supplied (B).

3. Adjust the horizontal/vertical direction of

the camera and then tighten the hinge
fixing screw (A).

4. Technical data

• Maximum carrying capacity: 6 kg
• Environment class: II

(A)

(B)

Fig. 3
