17
English
5.2 Cleaning
Wipe the product with a clean, dry cloth. If the device is very dirty, you can moisten the cloth with
lukewarm water.
Make sure that no liquids can enter the equipment as the device can be destroyed.
Never use chemical detergents as they could attack the surface of the device
6. Disposal
Devices with this marking should not be put in the household garbage. Dispose of the
product at the end of its lifetime according to the applicable regulations.
7. Technical data
Model number TVAC17000 TVAC17100
Adaption > 10 dB
Gain 10 dBi 16 dBi
Frequency range 2.4–2.5 GHz 4.9–5.875 GHz
Aperture angle, vertical 49.3 ° 14.9 °
Aperture angle, horizontal 52.4 ° 36.5 °
Polarisation Vertical
Front-to-back ratio 23.46 dB 27.03 dB
Output resistance 50 Ω ± 5 Ω
Max. load capacity 10 W
Contact
SMA socket
Weight 620 g
Dimensions (W x H x D) 140 x 165 x 16 mm
Fastens to Pole, wall
Protection class IP65
Operating temperature -30°C – +60°C
