14
English
To display the monitor display on another device, proceed as follows:
1. Connect the jack plug to the monitor ’s AV OUT.
2. Connect the RCA plug to the monitor as shown in the drawing.
7. Operation
To switch the monitor ON/OFF, press and hold the power button for at least 2 seconds.
Each time it is started, the monitor switches to live view and it selects the last view that was set.
If the icon is displayed, the monitor has correctly identified the SD card and it is working normally.
7.1 Live view
01:12:45 2011 05 01
14:30:11
Signal display
Channel display
Recording display: flashes during recording
Motion detection recording activated
