62
English
7.2 Aligning the camera
First, undo the black dome cover. Loosen the screws at the side on the bracket to align the lens.
The camera can be aligned in 2 axes.
Setting the angle of rotation
Rotation: 0° –360°
Setting the angle of inclination
Inclination: 0°
–65°
Do not forget to tighten up the screws again!
8. Inital start-up
The network camera automatically detects whether a direct connection between the PC and camera
should be made. A crossover network cable is not required for this.
Direct connection of the network camera to a PC/laptop
1. Ensure that a CAT 5 network cable is used.
2. Connect the cable to the Ethernet interface of the PC/laptop and the network camera.
3. Connect the power supply to the network camera.
4. Configure the network interface of your PC/laptop to the IP address 192.168.0.2 default
gateway to 192.168.0.1
5. Go to 8, to finish the initial set-up and establish the connection to the network camera.
