ABUS TVVR30004 Quick operating instructions User Manual
Page 25
25
English
Connect the hard disk
drive to the motherboard
with the data cable (small
connector) and the power
cable (large connector).
Now place the box over the
base plate of the recorder.
Ensure that the box is placed
along the guide rails.
Then secure the box and
the base plate with the 4
screws.
Connect your cameras to
the recorder.
5
6
7
8
