AAEON AEC-204 User Manual
Page 8
W a l l m o u n t C h a s s i s
A E C - 2 0 4
Chapter 2 Quick Installation Guide
2- 8
2.6 Installing the power supply and backplanes
The power supply is to be secured at the bottom of the chassis. The
fan and power cord connection (in the rear of the power supply)
should face the opening on the rear of the chassis
Step 1: Fasten the two screws of the power supply to the Chassis
Step 2: Fasten another two screws on the rear of the chassis to
provide additional support.
